Edge Highlighting Miniatures: A Two-Stage Resin Kit Guide

Edge highlighting puts a lighter line on a raised edge so the shape reads clearly. The useful part is choosing that line; a bright outline around everything can bury the very detail you wanted to show.

This guide is for hobby painters working on an unpainted resin figure kit. Three things shape the approach: the kit may still need preparation, the sculpt may combine hard armour with soft cloth, and a display piece will be seen from more than one angle. Those differences matter before you reach for the palest paint.

Remerlinds makes physical resin figure kits in the Netherlands, supplied unpainted for your own assembly and painting. The final sections explain how our finish levels affect your starting point and how to choose a small, manageable practice area on the project you already have.

Choose the edges before choosing the paint

A raised ridge gives an edge highlight somewhere to sit. Look first at a shield rim, a squared armour plate or a crisp accessory edge, then decide which parts should receive the most attention.

For this exercise, use a simple light direction from above and slightly in front. Hold the figure upright under your lamp and look at the upper edges. Choose one easy section that faces the imagined light. Keep this choice consistent when you turn the model to reach it with the brush.

You are making a painting decision, not measuring every reflection. A selective scheme can leave the lower rim quiet while giving the upper corner a brighter accent. A graphic scheme can outline more of the shape. Both are available to you, but start with one intention rather than changing rules halfway around the figure.

Write that intention in a few words beside your palette: upper shield, top of shoulder, front corner. This little plan is more useful than buying another detail brush before you know where the paint is going. It also gives you a stopping point. When those selected edges read clearly, you can judge whether the figure needs any more.

Start after preparation, primer and base colours

This is a painting step for a prepared surface. The exercise begins when the relevant area has its primer, base colour and any chosen shading in place, with each application dry according to the paint maker's directions.

Delivered Remerlinds kits have already been washed and cured in the workshop. Your starting work depends on the finish you ordered. Do not turn a highlighting tutorial into another production-cleaning routine. Check the parts and their intended fit before beginning the finish you want to keep.

If you have just opened the box, use the resin kit inspection checklist first. A missing component, an uncertain fit or a damaged detail belongs in that conversation before it disappears beneath primer. Painting cannot answer whether an unidentified part was meant to fit somewhere else.

Decide how you will reach the chosen edge. A loose shield can be easier to position than a shield enclosed between a torso and a cape. Plan around the kit's actual connections, and keep paint away from mating areas needed for assembly. Never force a joint merely to gain a better brush angle.

For practice, a plain accessory you already own is enough. There is no need to make a new purchase solely to paint your first controlled line. Pick a surface you are comfortable repainting, not the face or an intricate focal detail you have already spent an evening finishing.

Set up a palette you can read

Keep three separate paint portions available: your existing base colour, a modestly lighter first highlight and a brighter second highlight. The base colour stays on the palette because it is also your correction colour.

For a neutral-grey practice panel, choose a middle grey, a light grey and a paler grey. Set them in order with empty space between them. There is no universal dilution ratio in this exercise. Adjust a small working portion and test the mark it actually leaves, following the paint maker's thinning guidance.

A wet palette is optional. If you use one, the wet-palette setup guide explains its moisture control. The palette should help you keep the mixtures available; it should not make you ignore their behaviour. Check the working portion again when you return to it.

Use a pointed brush whose shape you can control. Load a little paint, remove the excess and try a short stroke on your practice surface. You want a mark that stays where you put it. If the brush deposits a blob before moving, unload and test again. If it leaves no useful mark, reload and reassess the mixture rather than pushing harder at a fragile detail.

Keep the test visible beside the model. Comparing an actual painted line with the next stroke is less ambiguous than trying to remember how a mixture looked ten minutes earlier. Label your own notes if useful; the model itself does not need a complicated colour recipe to begin.

Apply the first pass as a controlled guide

The first highlight establishes the path. Use the lighter of your two highlighting steps and aim for a continuous, modest line along the edge you selected, leaving the surrounding base colour visible.

Where the raised edge is accessible, let the side of the brush bristles make contact. Use light pressure and a controlled paint load. Where another part blocks that approach, reposition the model or use the tip carefully. The goal is deliberate contact with the edge, not a particular wrist pose.

For the practice panel, begin with one short stretch. Stop, set the model upright and inspect it before extending the line. This pause separates two decisions: whether the mark is going where you intended, and whether its brightness suits the surrounding colour. If either is wrong, one short stretch is a manageable place to correct it.

Do not chase a perfect whole-model result on the first pass. Complete your chosen section, then compare it with an untouched section. Leave the rest alone until you can describe what improved. If you cannot see a useful difference, adjust that one area rather than repeating the same uncertain decision around the entire sculpt.

Key takeaways

• Begin with one accessible edge and a moderate first highlight.
• Use controlled contact and paint load instead of extra pressure.
• Check the section upright before extending the treatment.

Add a narrower second pass and a corner accent

The second highlight should occupy less space than the first. Place the brighter colour on the upper or more exposed part of the existing line, leaving some of the first highlight visible around it.

Think of this as a hierarchy: the base covers the largest area, the first pass defines the edge, and the second pass draws attention to a smaller part. If the second colour completely replaces the first, you have lost that intermediate step. You can keep the simpler result or restore a little of the first colour before continuing.

Try the upper half of the practice edge first. Compare it with the lower half you left at the first stage. The comparison is the purpose of this exercise. You can see how a smaller, brighter mark changes the emphasis without committing to the whole rim.

A small bright point where selected edges meet can finish the accent. Reserve it for a corner you want the viewer to notice. A circle on every junction quickly becomes another pattern to manage, so begin with one. If the dot dominates the area, reduce it with the preceding colour and look again.

There is no requirement to use pure white, to add a third pass or to match a competition photograph. End the exercise when the chosen corner reads as intended from the distance where you expect to display the piece.

Key takeaways

• Keep the second highlight narrower and more selective.
• Leave the earlier paint stages visible.
• Use corner accents as emphasis, then stop and assess.

Correct the line without restarting the figure

A wandering highlight is a local painting problem. Once the paint is dry, use the neighbouring base colour to reduce its width, then restore the smaller highlight if necessary.

Keep the correction small. Identify the one side of the line that wandered and work there first. Repainting the entire panel every time makes it harder to see which change solved the problem. It also turns a short practice exercise into a much larger job than it needs to be.

What you see	What to try next
The line is too broad	Reduce it with the surrounding colour, then test a lighter touch.
A blob appears at the start	Unload the brush and make a test stroke before returning.
The bright step covers the first pass	Restore a little intermediate colour and shorten the bright section.
The whole area looks outlined	Repaint selected lower edges in the base colour and compare.
The corner attracts too much attention	Reduce the bright point before changing the rest of the figure.

Change one thing at a time. If you alter the brush, mixture, brightness and pressure together, you will not know which adjustment helped. Make two neighbouring test marks with one deliberate difference, then choose the more controllable result.

Save a quick photograph for your own notes. Use it to identify the next small correction, not as a demand that every enlarged mark must look flawless. Return to the physical figure before deciding to repaint a section that already works at its intended viewing distance.

Use softer treatment where the sculpt needs it

A crisp armour rim and a rounded cheek do not need the same painted boundary. Keep edge highlighting as one tool among your choices, especially on a figure that mixes hard accessories with cloth, skin and hair.

For this practice, leave the face alone and compare the shield rim with a broad cloak fold. The rim offers a clear boundary for a line. On the fold, decide whether you want a graphic stripe or a wider transition across the raised surface. Choose deliberately instead of carrying the shield treatment onto every neighbouring material.

This also helps when a figure looks too busy. Before adding another brighter colour, inspect where you have placed equal emphasis. You might keep the head and upper accessories clear while reducing some lower details. The decision is about the finished composition you want, not a compulsory checklist of every sculpted edge.

Keep special effects for another session if they distract from the exercise. A glowing lantern, reflective blade and fabric texture each introduce additional decisions. A neutral accessory with two visible edge stages gives you a simpler result to assess and a repeatable starting point for the next project.

Choose the preparation work you want to do

Remerlinds sells the unpainted resin project. Bronze, Silver and Gold describe workshop preparation before dispatch; none of those names means that the figure arrives with the highlights demonstrated here.

Bronze, DIY Ready, includes support removal, washing, curing and quality control, with sanding, filling and priming left to you. Silver, Detail Ready, adds light sanding of support marks and filling of drainage holes that would remain visible after assembly. You still assemble, address assembly seams, prime and paint.

Gold, Paint Ready, adds the further filling and sanding work described in the finish guide and primer in black, white or grey. You still assemble and paint. Primer establishes the starting surface; the base colours and highlighting remain your creative work.

Choose the service level around that division of work. If your immediate interest is brush practice, read the Bronze, Silver and Gold guide before choosing. For a future project, inspect the sculpt images in the resin figure kit catalogue for accessible surfaces you actually want to paint. A favourite character with one useful practice area is a better starting brief than a generic promise that any detailed kit teaches every technique.

Recommended reading

• Wet Palette for Miniatures: keep working mixtures organised and check their moisture.
• Understanding Finish Levels: separate workshop preparation from your own painting.
• Resin Print Quality Control: inspect a newly delivered kit before adding paint.

Finish one small area today

Choose an accessible edge on a prepared practice piece. Put the base colour and two lighter steps beside it, then make one test mark. Paint the first pass, add a shorter bright section and assess the result upright. Correct one thing if needed. Keep that finished area as your reference before moving to the next one.
