Dry Fitting Resin Figures Before Glue and Paint

Dry fitting is assembling parts without adhesive to check how they meet. It is the stage at which an awkward joint can still be examined, the assembly order can change and a hidden painting problem can be spotted without undoing a bond.

This guide is for builders of resin character kits. Three things decide the sequence: the shape of the actual joints, the overlap between components and the areas you want to paint separately. A 75 mm label or a scale ratio cannot tell you those details. Put the parts and their reference views on the table.

Remerlinds makes unpainted resin figure kits in the Netherlands. The inspection and assembly described here happen after delivery; the section on preparation explains how Bronze, Silver and Gold affect the work you plan.

Identify the parts before testing a joint

Work from the supplied parts diagram and reference views. Match each component to its position before trying to fit it. Two similar sleeves or hair pieces can look interchangeable while belonging on different sides of the figure.

Keep the small components in separate containers or their original bags. Put a note beside each group rather than writing directly on a visible resin surface. If the diagram uses identifiers, carry those onto your notes. A consistent name makes a later question to the workshop much easier to answer.

Start with the broad, recognizable components: base, body and any large separate costume pieces. Leave fragile accessories safely aside while you learn the main sequence. There is no advantage in balancing every tiny part on the model during the first inspection.

Compare the front, side and rear reference views. A component may appear to meet the body in one place while also passing behind another part. Look for those overlaps before assuming that a joint is wrong. A reference image establishes orientation; it does not justify forcing the parts into that pose.

Photograph anything that appears damaged or incomplete before modifying it. If a part has a crack, missing edge or uncertain residue, separate that issue from ordinary fitting. Use the contact page for an order-specific assessment. Cutting or sanding first can remove the evidence needed to understand the problem.

Check one mating pair without force

Bring the two intended parts together gently and watch where they first touch. The useful question is whether they reach the intended position naturally. Pressure is not a fitting tool.

Support each part close to a robust area. Avoid holding an arm by its fingers or a head by a narrow hair strand. Keep the joint over a clear surface so a released component has somewhere safe to land. A stable support under the body leaves you free to examine the smaller piece.

Check whether a locating feature enters in the intended direction. Some keyed joints have only one orientation. Turning a component slightly while keeping it clear of the socket is a way to inspect it; twisting a tight feature inside the socket is a different action and should be avoided.

Look from more than one angle. A shoulder may seem flush from the front while sitting proud at the rear. A foot can look aligned with its base while the whole pose leans away from the reference. Make a note of the specific mismatch rather than describing the kit as generally not fitting.

Keep the gap visible for a moment. Is it uniform, wider on one side, or caused by a feature that stops before the surrounding surfaces meet? Those observations guide the next inspection. Do not immediately decide that the whole mating face needs sanding.

If you need to squeeze the parts together to hide the gap, separate them again. A successful dry fit should let you understand the intended relationship without using the joint as a spring. Glue will not make an unexplained obstruction disappear.

Rehearse the full assembly order

A pair of parts can fit correctly and still become impossible to install after another component is attached. Build a sequence from the larger structure outward, checking every overlap before opening the adhesive.

For example, consider a body, a cloak and an arm crossing the chest. Test whether the cloak must slide behind the shoulder before the arm goes on. Then check whether that sequence leaves access to the inside of the cloak for painting. This is a rehearsal using your actual components, not a fixed assembly rule for every figure.

Use a simple numbered list on paper. Write the component, the direction it enters and anything that must already be in place. Add a separate note for parts that need to remain removable for painting. You can change this plan freely while everything is still dry.

Do not try to prove the sequence by balancing an unsupported complete figure. Check manageable groups and use photographs to record their relationship. If a heavy section will not stay in place without adhesive, support it rather than trusting a temporary balance.

Include the base in the rehearsal. A wide accessory or low cloak edge can change the order in which the figure meets its base. Check that you can reach the intended contact surfaces after surrounding pieces are installed.

Finally, rehearse how you will put the assembly down. A joint may be easy to hold for a few seconds but awkward to support during curing. Choose that resting arrangement now, when a failed rehearsal costs only another attempt.

Key takeaways

• Check overlapping parts as well as individual joints.
• Write down the sequence while it is easy to change.
• Prepare a stable resting position before adhesive.

Separate an obstruction from an assembly seam

A visible line does not automatically mean that the parts have failed to seat. Distinguish a blocked connection from a normal assembly seam. Removing material from a joint that already reaches its intended position can make alignment worse.

First confirm that you have the correct pair and orientation. Then inspect both surfaces under good light. Look for a local protrusion, loose debris or a locating feature that appears to bottom out. Record what you can actually see; a dark recess does not reveal its full internal depth.

If a localized surface adjustment is appropriate, work only on the identified area and recheck frequently. Keep the original contact geometry in mind. The aim is to remove an obstruction, not to make every surface uniformly smaller until the parts become loose.

Do not automatically enlarge a socket because the locating feature feels tight. Inspect both components first. The surrounding wall may be thin, and an uncontrolled enlargement can remove the feature that kept the pose registered. If you cannot establish the available material, ask before drilling.

A gap that remains after correct alignment may need filling later. That is a different job from correcting a fit that requires force. The assembly and finishing guide covers the transition from a sound joint to surface finishing.

Leave a suspicious bend or crack for a separate assessment. Do not clamp a warped component into place and rely on glue to hold it under strain. Send clear photographs showing the relaxed position and the intended fit. The workshop can advise on the actual part more usefully than a generic temperature or bending recipe can.

Plan painting access while the parts are separate

Dry fitting is also a chance to decide where your brush needs to go. Look behind hair, inside a cloak and beneath a crossed arm before committing to assembly. Keep a part separate only when doing so gives a useful advantage.

Hold your usual brush near the intended area without touching the figure. Can you see its point and approach the surface at a workable angle? If not, a painting subassembly may help. You are testing access, not painting through a maze just to keep the whole figure together.

Balance that access against the seam. A joint running across a broad visible surface may be easier to assemble and finish before colour. A naturally concealed connection can be a better place to separate the project. There is no universal instruction to paint every part individually.

Plan how to keep joint surfaces clear where the adhesive directions require direct contact with the substrate. Use a method suited to the primer and paint system, and check it on a test surface first if needed. Do not assume a thick painted layer inside a socket will leave the original fit unchanged.

Keep colours consistent across separate pieces by working from recorded mixes and adjacent samples. Place the parts near each other while judging the scheme. A sleeve painted in isolation may look right until it sits next to the torso.

Record where the final connection will be made and how it will be supported. Painting separately does not remove the need for a later dry fit. It moves that check to a stage at which protecting the finished surfaces matters even more.

Prepare support before choosing adhesive

Choose a support that holds the intended position without squeezing delicate detail. A broad cradle beneath the body and a separate rest under an overhanging part can be more useful than a clamp across the sculpt.

Test the support with the dry components. Check where its pressure falls and whether it can shift. Keep hair, fingers and thin costume edges clear. A material described as soft can still press against a vulnerable detail if the weight is concentrated there.

If temporary putty or tape is part of your plan, first assess its suitability for the actual surface. Keep it away from areas where residue or removal would create a problem. Do not assume a temporary fixing is harmless to a fresh primer or paint layer.

Choose the adhesive according to the resin, the joint and the manufacturer's instructions. Check working time, cure time and how much adjustment it allows. A fast initial hold does not tell you that the joint is ready to carry the entire assembly.

Keep the adhesive closed during rehearsal. Lay out the intended applicator and practise the movement with dry parts. You should know where both hands go, how the component enters and where the assembly will rest before the working time starts.

Pinning is an additional structural operation, not an obligatory part of dry fitting. It requires suitable geometry and a controlled drilling plan. The pinning guide explains that assessment. Do not drill a narrow component merely because the figure's scale sounds large.

Repeat the fit after relevant surface work

Return to the joint after any work that could alter its contact surfaces or access. A fit checked on the delivered parts is a starting observation. It is not a permanent guarantee after sanding, filling, priming or painting.

Compare the new result with your earlier photograph. If a gap appears, identify what changed before removing material. A small build-up on a mating face deserves a different response from an alignment problem that was present from the beginning.

Check the sequence again if you change the subassemblies. Moving one part into a painting group may affect when another can be attached. Update the written order instead of trusting a plan that no longer describes the components on the table.

Keep the final dry check brief and controlled on painted parts. Use the holder and supports you planned. Avoid repeated rubbing at a tight connection to make it seat; investigate the interference while protecting the surrounding finish.

When the joint meets as intended, the next step should be clear: adhesive application, support and the specified cure. If any of those steps still feels improvised, stop and complete the rehearsal. Confidence here should come from a repeatable sequence, not from pressing harder.

Key takeaways

• Recheck after work that can change a joint.
• Compare with the original dry-fit record.
• Resolve interference before final assembly.

Choose the preparation work you want to do

Remerlinds kits arrive with supports removed, washed and cured. Bronze, Silver and Gold describe different preparation services, so read the option you selected alongside the actual parts in front of you.

Bronze leaves sanding, filling and primer to the builder. Silver adds attention to support marks and visible holes. Gold includes further preparation and primer. Assembly relationships still deserve inspection; a prepared surface does not tell you which overlapping part must go on first.

Browse the anime figure-kit collection for the character and pose you want to build. Use each listing's dimensions, views and parts information. A chibi label does not promise fewer joints, and a 75 mm height does not equal a particular display-scale ratio.

For a first project, prioritize a pose whose main connections and painting access you can understand. If the reference views leave an important joint unclear, ask about that kit before ordering. A specific question about the cloak or base is more useful than a general request for the easiest model.

Recommended reading

Use the next guide for the work the dry fit actually revealed.

• Preparing a resin figure kit places inspection and fitting within the full preparation sequence.
• Pinning resin figures explains when a reinforcement deserves consideration.
• Assembly and finishing follows a sound joint through adhesive and seam work.

Rehearse one complete connection

Choose the first major joint, identify both parts and bring them together without force. Check it from several angles, write down its place in the sequence and prepare its support. Leave the glue closed until you can repeat that connection calmly.
