Kitbashing Resin Miniatures: Plan a Small Conversion

Kitbashing resin miniatures means combining components to change a model's original design. A different paint scheme is a painting choice; a replacement accessory or a part borrowed from another kit creates an assembly problem as well as a visual one.

This guide is for a purchased resin figure kit: 1. it arrives unpainted; 2. its parts were designed for their own sculpt; 3. another kit's components are not automatically interchangeable. Start with one modest change that you can assess before cutting or gluing.

Remerlinds makes physical resin figure kits in the Netherlands, with Bronze, Silver and Gold workshop preparation. The final section explains how those services relate to a conversion you plan yourself. First, decide what you want to change and why.

Choose one change and keep the original build understandable

Write the proposed conversion in one sentence. Adding a small decorative pack to a suitable area is a different project from changing a shoulder angle, replacing a leg or moving the figure's weight onto another support. Name the actual component and intended result.

For a first conversion, choose a change you can examine while the original kit remains intact. An accessory held beside the figure gives you a useful preview. A major cut made before you know how the new part will sit removes that opportunity.

Keep the supplied pieces together and photograph the original arrangement. Put any donor part in a separate tray with a note identifying its source and material. This is ordinary project organization: it helps you distinguish what belongs to the kit from what you have added.

Decide what success looks like from the intended display view. Perhaps the new pack should be visible from the side without covering a sculpted clasp. That is specific enough to evaluate. Make the figure more detailed gives you no reason to stop adding parts.

Check proportions, attachment and clearance separately

A shared scale label does not establish a shared connection. Compare the actual parts in three ways: how they look together, where they can attach and whether they leave room for the rest of the build. Passing one check does not answer the other two.

For proportions, place the accessory beside the figure and view both from the same direction. Compare its width and depth with nearby features. Use a ruler or caliper where an actual measurement will help, but do not infer a standard socket size from the figure's advertised height.

For attachment, identify the surfaces that would meet. A flat-backed accessory and a flat area may offer a simpler starting point than two unrelated keyed joints. Even then, the materials, contact area and load still need an appropriate adhesive and assembly plan.

For clearance, consider neighbouring arms, clothing, effects and the base. A pack that looks right from the back may prevent a cape from reaching its intended position. Check the approach needed to install the other components, not just the empty space around the finished arrangement.

Key takeaways

• Compare the real parts instead of relying on scale labels.
• Assess appearance, attachment and clearance as separate decisions.
• Keep the complete assembly sequence in view while planning one change.

Dry fit without using force to make the idea work

Dry fitting means checking the arrangement without permanent adhesive. Start with the original kit's intended connections so you understand how it assembles, then assess the additional part. Our arrival inspection guide helps identify concerns before a conversion obscures them.

Support parts near the connection you are examining. Bring them into position gently and stop at resistance. Do not use a thin wrist, antenna or cape edge as a lever. For an accessory with no matching connection, hold it adjacent to the proposed position without pressing it into the sculpt.

Take front, side and rear photographs of the mock-up. Keep the camera position similar when comparing alternatives. Put the original arrangement and your proposed change side by side in your notes, then choose based on the view you actually want to display.

If you use a temporary holding product, check its suitability for the surface and its removal method first. Do not assume tape or putty is harmless on every coating or delicate detail. A hand-supported comparison may be enough to reject a poor fit without attaching anything.

Record unresolved questions explicitly. An accessory that looks right but has no sound attachment plan is still a proposal. Leave it separate while you decide whether to alter the accessory, choose another part or keep the original sculpt.

Keep decorative additions separate from structural changes

A decorative pouch and a replacement supporting leg carry different consequences. The first adds a feature to an existing build; the second changes how the figure is supported. Decide which kind of change you are considering before choosing tools.

For a decorative addition, ask whether it interferes with the original support or assembly. Keep its placement clear of joints that still need filling, painting or access. Use a sample or spare material when learning a new attachment method rather than experimenting on an irreplaceable face or hand.

Cutting, drilling and repositioning deserve a specific plan for the part's geometry. There is no universal pin diameter or drilling depth for a resin miniature. If reinforcement is needed, its position and dimensions must suit the actual components; a generic tutorial cannot establish that from a scale label.

Do not try to bend a rigid part into compatibility with steady cold pressure. If the proposed fit requires reshaping, pause and assess another arrangement or seek guidance for that specific component. This beginner workflow does not depend on heating a supplied piece or forcing it into a new pose.

A useful first conversion can be deliberately small. Choosing a different accessory or adding a separate scenic element gives you design decisions to make while keeping the original figure's support arrangement understandable.

Select adhesive for both materials and the connection

Check the adhesive manufacturer's stated materials and application instructions. Cyanoacrylate adhesives are commonly used for resin miniature assembly, but the correct product and joint still matter. A plastic glue designed to melt plastic surfaces together is not a universal adhesive for a resin conversion.

Identify both sides of the connection before selecting glue. A donor accessory could be a different resin, plastic, metal or a coated material. Its colour does not identify it. If you cannot establish the material, ask the supplier rather than assuming it behaves like the supplied kit.

Plan the support needed while the adhesive sets and the time required before later handling. Follow the actual product's instructions for surface preparation, amount and curing conditions. Do not convert a fast-setting claim into permission to load the joint immediately.

Read the safety information as part of choosing the product. Keep adhesive away from skin and eyes, use the specified ventilation and handling precautions, and keep the work out of reach of children. The equipment selected for sanding particles does not automatically address adhesive vapours.

Keep the adhesive step tidy and limited to the intended contact. If the trial arrangement has a large mismatch, stop and resolve that geometry before bonding. More glue is not a substitute for knowing how the added part is meant to sit.

Plan seams and paint access before committing assembly

There is no single correct rule that every figure must be fully painted before gluing. Some connections need assembly and seam work before primer. Other areas are easier to paint separately because a later component would block access. Decide by looking at the actual sculpt.

List each planned subassembly and the surface it exposes or hides. If a new accessory covers a jacket seam, decide when that seam will be finished. If a cape blocks a brush from reaching the back, decide which areas need painting before the cape is attached.

Keep intended bonding surfaces prepared as the adhesive instructions require. Do not assume a painted or varnished contact is equivalent to the underlying material. Plan masking or protected contact areas before painting rather than scraping a finished surface as an unplanned last step.

Where a cosmetic gap needs filler, select a material suitable for that application and follow its working and curing instructions. Filler can help blend a visible transition; it is not automatically the structural support for an ill-fitting component. Resolve attachment separately.

Key takeaways

• Assemble according to seam work and brush access.
• Keep bonding surfaces appropriate for the selected adhesive.
• Treat cosmetic filling and structural attachment as different jobs.

Make preparation and finishing serve the conversion

Use a short work list for the areas affected by your change. An accessory addition does not require sanding every supplied surface or varnishing between every painting stage. Each operation should have a clear purpose in the planned build.

If material removal is needed, identify the material and the dust-control method before starting. The resin sanding-dust guide covers a small abrasive task and cleanup. Add the donor material, filler and coatings to that assessment when they are involved.

Test the proposed paint and finish on suitable spare material. Try the colours of the added part beside the figure's palette before committing the whole accessory. A repeated accent colour can visually connect an addition; a different finish can make it stand apart if that is the effect you want.

Follow the instructions for primer, paint and any varnish you choose. Varnish is a deliberate finishing step, not a mandatory barrier after every layer. Test compatibility and the intended sheen on your sample instead of introducing another product because a generic sequence includes it.

When the conversion includes the ground around the figure, use the scenic figure-basing guide to plan that surface. Keep the figure's contact areas and assembly access clear while testing decorative additions.

Review the finished arrangement without stress testing it

After completing the required setting and curing steps, inspect the added part under good light. Compare it with your original plan and check that neighbouring components occupy their intended positions. Look for an unresolved gap or a visibly displaced connection.

Do not bend, shake or tug a delicate conversion to prove its strength. Support the build appropriately when moving it, and avoid lifting by the added accessory. A successful photograph does not establish how much force the joint can withstand.

Check the finished footprint again before choosing a case or shelf position. The added part may project beyond the original base even if the figure's height is unchanged. Include the new shape when planning clearance and access for moving the piece.

Keep the donor-material and adhesive notes with your project photographs. If something changes later, those details help explain what was used and where. They also give you a useful record if you want to repeat the visual idea on another build with different components.

Key takeaways

• Inspect the arrangement without pulling on the new joint.
• Move the figure using its intended support, not the accessory.
• Measure the completed conversion and retain its material notes.

Choose a Remerlinds kit close to the result you want

Choose a sculpt you would still enjoy building if the proposed conversion proves unsuitable. Remerlinds sells physical unpainted kits; the catalogue is not presented as a universal interchangeable-parts system. A shared sculptor, theme or nominal scale is not a promise that parts will swap.

Check the individual listing for included parts and dimensions. If a conversion depends on a hidden connection or the back of a component, ask about that specific kit and area before ordering for the purpose. Do not assume spare components or altered sculpts are available.

All finish levels arrive with supports removed, washed, cured, test fitted and checked. Bronze leaves sanding, filling and primer to you. Silver adds light sanding of support marks and filling of drainage holes visible after assembly; assembly seams, primer and painting remain your work.

Gold adds the specified seam and joint filling, sanding, extra preparation and black, white or grey primer. You still assemble and paint the kit. These services describe preparation of the supplied sculpt; they do not include an unagreed conversion or guarantee the fit of a donor part.

Before you begin, put the original kit, the candidate accessory and your one-sentence change together on the desk. Check proportions, attachment and clearance. If those three decisions are clear, plan the next operation; if they are not, keep the parts separate while you resolve them.
